| Video Inputs |
HDMI: 4 x HDMI type A
NDI: Up to 8 compatible devices |
| Video Output |
HDMI: 2 x HDMI type A
Display: 1 x DisplayPort, 1 x HDMI, 1 x DVI
Interface/Multiview: 1 x HDMI, 1 x DVI |
| Other I/O |
Ethernet: 1 x RJ45
USB 3.0: 4 x USB Type-A
USB 2.0: 2 x USB Type-A
Audio: 1 x Analog multichannel, 1 x optical S/PDIF |
| Media |
Five integrated digital media sources for video, graphics, and sounds (two DDRs, two GFX, and Sound), and 15 buffers |
| Downstream Keyer |
Two primary DSK channels
One additional key layer per M/E bus (each with independent transition controls, 3D DVE, scaling, cropping, and integrated TransWarp effects) |
| Audio Inputs |
Line Level: 2 x 1/4\" (left and right channels)
Microphone: 1 x 1/4\" |
| Audio Outputs |
Line Level: 2 x 1/4\" (left and right channels)
Headphone: 1 x 1/4\" |
| Video Resolution |
1080p 30/24
1080i 60
720p 60/30/24
480i 60 |
| Playback Media Formats |
Video: AVI, DV, DVCPro, DVCProHD, FLV, F4V, H.263, H.264, MOV, MKV, MJPEG, MPEG (1, 2, all profiles, program, or transport streams), MP4, WMV, WebM, and more
Image: PSD, PNG, TGA, BMP, JPEG, EXR, RAW, TIF, and more
Audio: AIFF, MP3, WAV, and more |
| Latency |
Between 1 and 2 frames |
| Processing |
Video: 4:4:4:4, 32-bit floating point
Audio: Four channels, 96 kHz, 32-bit floating point |
| Recording |
Up to four simultaneous video input or output signals in QuickTime (XDCAM HD compatible, 4:2:2 encoding, 24-bit audio), MPEG-2 (High or Normal profile), AVI (SpeedHQ), or H.264 (High or Web quality) file formats |
| Storage |
1 x 750 GB internal drive, approximately 15 hours of HD video |
| Display |
None |
| Dimensions |
4.6 x 9.2 x 7.9\" / 11.7 x 23.4 x 20.1 cm |
| Weight |
9 lb / 4.1 kg |
