Inputs
Connector - XLR, balanced
Outputs
Connectors - 5 x XLR, balanced
System
Frequency respons:
20 Hz to 22 kHz (± 0.05 dB)
THD + N (distortion):
< 0.01% @ 1 kHz,+4 dBu
Signal-to-noise ratio:
121 dB
CMRR:
98 dB typical
Insertion loss:
0.05 dB @ 100 kΩ, 0.7 dB @ 600 Ω
Power requirement:
Passive
Physical
Dimensions (W x D x H):
118 x 112 x 64 mm (4.6 x 4.4 x 2.5")
Weight:
0.43 kg (0.9 lbs)
Warranty
10 years after registration
Connector - XLR, balanced
Outputs
Connectors - 5 x XLR, balanced
System
Frequency respons:
20 Hz to 22 kHz (± 0.05 dB)
THD + N (distortion):
< 0.01% @ 1 kHz,+4 dBu
Signal-to-noise ratio:
121 dB
CMRR:
98 dB typical
Insertion loss:
0.05 dB @ 100 kΩ, 0.7 dB @ 600 Ω
Power requirement:
Passive
Physical
Dimensions (W x D x H):
118 x 112 x 64 mm (4.6 x 4.4 x 2.5")
Weight:
0.43 kg (0.9 lbs)
Warranty
10 years after registration
