- Rozmiar: 5,2\' / 13.2 cm
- Typ: IPS-Type LCD
- Rozdzielczość: 1920 x 1080 423 ppi
- Format: 16:9
- Jasność: 1000 cd/m²
- Głębia: 8-Bit+FRC (1.07 Billion Colors)
- Wsparcie: Zaawansowane HDR
- Gamut: 100% Rec. 709
- Wbudowane funkcje: Anamorphic De-Squeeze, Blue Only, False Color, Focus Peaking, Pixel Zoom, RGB Parade, Scaling, Vectorscope, Waveform, Zebra
- Wejścia / wyjście video: 1 x HDMI Type A (HDMI 2.0) Input, 1 x HDMI Type A (HDMI 2.0) Output
- Wbudowany dźwięk: HDMI: 2-Channel, HDMI: 8-Channel\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\
- Wejścia / wyjścia audio: 1 x 1/8\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\" / 3.5 mm Mic/Line Input, 1 x 1/8\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\" / 3.5 mm Headphone Output
- Zasilanie: 1 x D-Tap Input, 1 x NP-F
- Format wideo: HDMI (8/10-Bit 4:2:2), 8K Raw: 30, 4K Raw: 120/60/30, DCI 4K: 120/60/50/30/25/24, UHD 4K: 60/50/30/25/24, 1080p: 120/60/50/30/25/24, 1080i: 60/50, 720p: 60/50, Krzywa gamma, Rec709, Konwersja sygnału wideo, HDMI to SDI, DCI 4K: 60/50/30/25/24, UHD 4K: 60/50/30/25/24, 1080p: 120/100/60/50/30/25/24, 1080i: 60/50, 720p: 60/50
- Timecode: Tak
- Konwersja rozwijana: 2:2, 3:2
- Wyzwalacz kamery: HDMI
- Pre-Roll Record: 4K: 2 Seconds, Full HD: 8 Seconds
- Formaty kodowania: Up to 7680 x 4320, ProRes 422, HQ, LT, Raw, Raw HQ 8/10-Bit 4:2:2 at up to 120 fps, H.265 422 10-Bit 4:2:2 at up to 120 fps, H.265 422 8/10-Bit 4:2:0 at up to 120 fps, DNxHR HQ, HQX, LB, SQ 8/10-Bit
- Maksymalna liczba ścieżek audio: 12
- Znakowanie metadanych: 10
- Wymagania dotyczące zasilania: 6.2 to 16.8 VDC
- Pobór energii: 10-22 W
- Zasilanie bateryjne: 1 x Sony L-series
- Wymiary: 151 x 91.5 x 31.5 mm
- Mocowanie: 2 x 3/8\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\"-16 Female
- Waga: 360 g
