Power to LED 120W
Flicker Free – Tested with Phantom Camera up to 40.000FPS
Power Consumption
DMX Data link USITT DMX512-A
This product uses a 5-pin XLR for DMX input and output.
Use a shielded data cables.
Do not overload the daisy chain. Up to a maximum of 32 devices can be used on a single DMX chain.
DMX Channels
2 for Remote Phosphors
4 for Variwhite
LED BARS Lifetime
50.000 hours with 70% Lumen Maintenance
Protection Type IP 22
Max. Housing Surface
Temperature 70° C
Weight of Fixture with yoke
M.O. : 4,1 kg.
P.O. : 5,3 kg.
Flicker Free – Tested with Phantom Camera up to 40.000FPS
Power Consumption
- Europe: 140W @ 230 V 50-60 H
- America: 150W @ 120 V 50-60 Hz
DMX Data link USITT DMX512-A
This product uses a 5-pin XLR for DMX input and output.
Use a shielded data cables.
Do not overload the daisy chain. Up to a maximum of 32 devices can be used on a single DMX chain.
DMX Channels
2 for Remote Phosphors
4 for Variwhite
LED BARS Lifetime
50.000 hours with 70% Lumen Maintenance
Protection Type IP 22
Max. Housing Surface
Temperature 70° C
Weight of Fixture with yoke
M.O. : 4,1 kg.
P.O. : 5,3 kg.
