Application
Broadcast ENG
Mount
M58-Mount
Resolution
2/3"
Standard resolution
HD
Initial focal length
4,5 mm
Zoom
12x
Extender
yes (2x)
Focal length
4.5 to 54 mm (1x), 9-108 mm (2x)
Maximum relative aperture
F1.8 (4.5-41mm) F2.4 (54 mm
Minimum Focus Distance (MOD)
0,3 m (from the front lens
Object Size at MOD (16:9, w / o ext)
757x425 mm (4.5 mm), 59x33 mm (54 mm)
Object Size at MOD (16:9, m. Ext)
373x210 mm (9 mm), 31x17 mm (108 mm)
Angle (16:9, w / o ext)
93 ° 38 'x 61 ° 50' (4.5 mm), 10 ° 9 'x 5 ° 43' (54 mm)
Angle (16:9, m. Ext)
56 ° 06 'x 33 ° 20' (9 mm), 5 ° 05 'x 2 ° 52' (108 mm)
Ratio Converter
no
Image stabilizer built
no
PF Assistance System
no
Engine
Zoom, Iris (auto / manual)
Filter Size
M127x0, 75 (in the sun visor)
Front diameter
Broadcast ENG
Mount
M58-Mount
Resolution
2/3"
Standard resolution
HD
Initial focal length
4,5 mm
Zoom
12x
Extender
yes (2x)
Focal length
4.5 to 54 mm (1x), 9-108 mm (2x)
Maximum relative aperture
F1.8 (4.5-41mm) F2.4 (54 mm
Minimum Focus Distance (MOD)
0,3 m (from the front lens
Object Size at MOD (16:9, w / o ext)
757x425 mm (4.5 mm), 59x33 mm (54 mm)
Object Size at MOD (16:9, m. Ext)
373x210 mm (9 mm), 31x17 mm (108 mm)
Angle (16:9, w / o ext)
93 ° 38 'x 61 ° 50' (4.5 mm), 10 ° 9 'x 5 ° 43' (54 mm)
Angle (16:9, m. Ext)
56 ° 06 'x 33 ° 20' (9 mm), 5 ° 05 'x 2 ° 52' (108 mm)
Ratio Converter
no
Image stabilizer built
no
PF Assistance System
no
Engine
Zoom, Iris (auto / manual)
Filter Size
M127x0, 75 (in the sun visor)
Front diameter
95 mm
