Frequency Response:
- 20Hz to 20kHz (+/- 1.0dB)
Gain:
- Line Out Lo Gain: 40dB, Hi Gain: 60dB
- Mic Out Lo Gain: 10dB, Hi Gain: 30dB
Maximum Input Level:
- Lo Gain: -15dBu
- High Gain: -35dBu
Output Clipping Level:
- Line Output: +25dBuMic Output: -5dBu
Dynamic Range:
- 100dB
THD+N:
- Lo Gain: 0.012% (+4dBu output, 1kHz)
- Hi Gain: 0.06% (+4dBu output, 1kHz)
Channel Separation:
- Lo Gain: 85dB (+4dBu output, 1kHz)
- Hi Gain: 80dB (+4dBu output, 1kHz)
Metering (Tri-Color LED):
- Green -40dBu to 16dBu
- Yellow -16dBu to +4dBu
- Red Over +4dBu
Powering:
- External DC Input Jack (12-16V)
- Pin 1 = (-), Pin 2 = (+)
Dimensions:
- 126 mm x 96 mm x 40 mm
- 4.96” x 3.78” x 1.57”
Weight:
- 374g (0.82lbs)
